Simpson TNT25600H Description
The Simpson Strong-Tie Titen Turbo Screw Anchor is a heavy-duty fastener designed for quick and easy installation in concrete and masonry applications. Featuring a patented torque reduction channel, it ensures smooth driving with less torque and superior holding power.
Simpson TNT25600H Includes
- (100) 1/4 x 6 Titen Turbo Screw Anchor
Simpson TNT25600H Features
- Patented Torque Reduction Channel reduces binding and snapping
- Available in multiple coated versions
- Hex head design for secure fastening
- Superior tension load performance
- Designed for use with impact drivers or cordless drills
- Code listed for uncracked concrete and masonry applications
Simpson TNT25600H Applications
- Electrical boxes and conduits
- Switch boxes and light fixtures
- Windows and thresholds
- Basement furring strips
- Shelf mounting to concrete/CMU
- Handrails
Simpson TNT25600H Installation Overview
- Drill a hole using the specified diameter carbide drill bit
- Position fixture and insert screw
- Tighten using a drill and Titen Turbo screw installation tool
Simpson TNT25600H Specifications
| Material | Carbon Steel |
| Finish | Blue Zinc |
| Diameter | 1/4″ |
| Length | 6″ |
| Drill Bit Size | 3/16″ |
| Drive Type | 5/16″ Hex |
| Head Type | Hex Head |
| Quantity | 100 |
NOTE: Ensure the correct fasteners are installed in the correct position to achieve published load values
