Simpson Strong-Tie Stb2-625004Ss 5/8″ X 5″ Type 304 Stainless Steel Wedge Anchor – 2-Piece, Unassembled, 20-Pack

Description

Simpson STB2-625004SS Description

The Strong-Bolt 2 Wedge Anchor is a reliable solution for anchoring in cracked or uncracked concrete, made from durable 304 stainless steel.

Simpson STB2-625004SS Includes

• (20) Strong-Bolt 2 Wedge Anchor

Simpson STB2-625004SS Features

• Chamfered top designed to prevent mushrooming during installation
• Qualified for static and seismic loading conditions
• Suitable for horizontal, vertical and overhead applications
• Qualified for minimum concrete thickness of 3 1/4″
• Standard ANSI fractional sizes
• Tested per ACI355.2 and AC193

Simpson STB2-625004SS Applications

• Concrete anchoring in cracked or uncracked surfaces
• Seismic loading applications
• Horizontal, vertical, and overhead installations

Simpson STB2-625004SS Installation Overview

1. Drill a hole using a carbide drill bit matching the anchor diameter.
2. Clean the hole using compressed air.
3. Assemble the anchor with nut and washer.
4. Insert the anchor into the fixture and drive it into the hole.
5. Tighten to the specified torque.

Simpson STB2-625004SS Specifications

NOTE: Ensure proper installation torque is applied to achieve optimal performance.
