Description
Simpson Strong-Tie THDB62400H4SS Description
The Titen HD Screw Anchor is a high-performance, corrosion-resistant fastener designed for secure anchoring in concrete and masonry. Made from 304 stainless steel, it is ideal for exterior applications.
Simpson Strong-Tie THDB62400H4SS Includes
- (10) Titen HD Screw Anchor 5/8 in. x 4 in.
Simpson Strong-Tie THDB62400H4SS Features
- Corrosion-resistant 304 stainless steel construction
- Patented thread design with serrated cutting teeth for easy installation
- Self-undercutting and non-expansion design
- Tested in accordance with ACI355.2, AC193, and AC106
Simpson Strong-Tie THDB62400H4SS Applications
- Exterior applications requiring corrosion resistance
- General anchoring in concrete and masonry
Simpson Strong-Tie THDB62400H4SS Installation Overview
- Drill a hole in the base material using a carbide drill bit of the same diameter as the anchor.
- Insert the anchor through the fixture and into the hole.
- Tighten the anchor until the hex-washer head contacts the fixture.
Simpson Strong-Tie THDB62400H4SS Specifications
| Material | 304 Stainless Steel |
| Diameter | 5/8 in. |
| Length | 4 in. |
| Drill Bit Size | 5/8 in. |
| Drive Type | 15/16 in. Hex |
| Fixture Hole Size | 3/4 in. – 13/16 in. |
| Head Type | Hex Head |
| Quantity | 10 |
NOTE: Use a Titen HD screw anchor one time only — installing the anchor multiple times may result in excessive thread wear and reduce load capacity.
