Description
Simpson HUC210-3Z Description
The Simpson HUC210-3Z is a concealed-flange joist hanger designed for triple 2×10 joists, featuring a ZMAX finish for enhanced corrosion resistance.
Simpson HUC210-3Z Includes
- (1) Concealed-Flange Joist Hanger for Triple 2×10
Simpson HUC210-3Z Features
- Concealed flange design for a clean appearance
- ZMAX galvanized finish for corrosion resistance
- Compatible with triple 2×10 joists
- Heavy-duty construction for structural integrity
- Requires specified fasteners for optimal performance
Simpson HUC210-3Z Applications
- Structural framing requiring concealed flange hangers
- School and institutional buildings needing enhanced strength
- Wood-to-wood connections in residential and commercial projects
Simpson HUC210-3Z Installation Overview
- Use all specified fasteners
- Fill round and triangle holes for maximum load values
- Joists sloped up to 1/4:12 achieve load tables
- Can be welded to steel members following technical guidelines
Simpson HUC210-3Z Specifications
| Finish | ZMAX |
| Material | Carbon Steel |
| Fasteners required | Face – (18) 0.162″ x 3-1/2″ Nails, Joist – (10) 0.148″ x 3″ Nails |
| For Treated Lumber | Yes |
| Height | 8-1/16″ |
| Joist size | Triple 2″ X 10″ |
| Thickness | 14 Gauge |
| Width | 4-11/16″ |
NOTE: The correct fasteners installed in the correct position must be used to achieve published load values
