Simpson Strong-Tie Htt5Kt 16″ Heavy Tension Tie Kit – G90 Galvanized For Wood-To-Concrete Anchoring

Description

Simpson HTT5KT Description

The HTT5KT Heavy Tension Tie Kit is designed for wood-to-concrete connections, offering high load capacity and durable construction for residential and commercial applications.

Simpson HTT5KT Includes

• (1) 16″ Heavy Tension Tie
• (1) Set of Fasteners

Simpson HTT5KT Features

• High Load Capacity: Achieves allowable loads up to 7,650 lbs.
• Optimized Design: Features a four-fold seat and tapered base to reduce deflection.
• Versatile Installation: Compatible with standard pneumatic nail sizes and Strong-Drive® SD Connector screws.
• Durable Construction: Made from 10-gauge galvanized steel for corrosion resistance.

Simpson HTT5KT Applications

• Wood-to-concrete connections in residential buildings.
• Light-frame commercial construction requiring tension resistance.
• Retrofit and new construction projects demanding high load capacity.

Simpson HTT5KT Installation Overview

1. Install using specified nails or Strong-Drive® SD Connector screws.
2. Ensure the use of a 3/4″ diameter anchor bolt and standard cut washer.
3. Verify wood member size meets minimum requirements of 3″ x 3 1/2″.

Simpson HTT5KT Specifications

NOTE: Ensure proper installation by using the specified fasteners and anchor bolt to achieve published load values
