Description
SAPF209-26 stamped steel bearing is a 4-bolt flange bearing designed for light-duty industrial and agricultural applications. The superior quality stamped steel housing encases a performance C3 precision 1-1/2″ insert bearing that utilizes an eccentric locking collar for securing onto a shaft. SAPF209-26 bearings are more economical than their cast counterparts but offer excellent performance in bearing applications; the four-bolt flange stamped steel housing allows for great mounting when the shaft is positioned perpendicular to the bearing. Utilizing four mounting holes, the SAPF209-26 1-1/2″ bearing has incredible holding power and stability. Additionally, our SAPF209-26 stamped steel bearing features a zinc plated housing for added protection against the elements in corrosive or outdoor applications. For more information or to get a quote on our SAPF209-26 bearing, contact our customer support team, and we will be happy to assist you!
SAPF209-26 Bearing Dimensions
- Part #: SAPF209-26
- Bearing ID: 1-1/2
- Dimension (a): 5-55/64″
- Dimension (e): 4-49/64″
- Dimension (g): 9/64″
- Dimension (c): 7/8″
- Dimension (s): 1/2″
- Dimension (f): 3-13/16″
- Dimension (L): 1.720″
- Dimension (n): 0.374″
- Dimension (W): 2-1/2″
- Bolt Size: 1/2″
- Number of Bolt Holes: 4
- Insert Bearing #: SA209-26
- Housing #: PF209
- Weight: 3.74 LBS
