Description
SALF204-12 bearing is a 3/4″ bore two-bolt light-duty flange bearing that utilizes an eccentric locking collar device to secure to a 3/4″ shaft. SALF204-12 flange bearings are designed for circumstances where the bearing is mounted to a surface perpendicular to the shaft axis and can fit in more space-restricted areas while still offering excellent stability with two mounting holes. Our superior SALF204-12 bearing with a 3/4″ bore is equipped with a premium C3 precision insert bearing housed within a high-strength solid-base cast-iron housing. Additionally, our SALF204-12 bearing has added features that improve the overall life and performance of the unit, such as; a steel retainer, wide inner-ring, anti-rotation device, and relubricating capabilities. SALF204-12 bearings are commonly used in applications such as; construction equipment, agricultural equipment, forestry, aggregate, conveyor systems, and many more. Our SALF204-12 bearing is dimensionally made to industry standards, meaning it interchanges with just about any brand out there. Contact our customer support team for further information or to get a quote on our SALF204-12 bearings, and we will be happy to assist you!
SALF204-12 Bearing Dimensions
- Part #: SALF 204-12
- Shaft Diameter (d): 3/4″
- Dimension (A): 3.54″
- Dimension (E): 2.815″
- Dimension (I): 0.43″
- Dimension (G): 0.43″
- Dimension (L): 0.79″
- Dimension (S): 0.39″
- Dimension (B): 2.40″
- Dimension (Z): 1.38″
- Dimension (Bi): 1.2205″
- Dimension (N): 0.2756″
- Dimension (M): 0.5709″
- Bolt Used: 5/16
- Dynamic Load Rating (LBS): 2,883
- Static Load Rating (LBS): 1,496
- Bearing Insert: SA 204-12
- Housing Number: LF 204
- Weight (LBS): 1.3
