Description
SafeWaze 023-8091 Description
Temporary 2-person horizontal lifeline with up to 65 ft galvanized cable, compact housing with collapsible crank, smooth payout and easy tensioning, built-in fall indicator, and O-rings to minimize cable wear.
SafeWaze 023-8091 Includes
- (1) Quadrant Retractable Horizontal Lifeline
- (2) O-rings
- (1) Power drill retraction adapter
SafeWaze 023-8091 Features
- Set cable length up to 65 ft
- Quick setup with smooth payout
- Lightweight, compact design with collapsible crank
- Captive eye and carabiner connection points
- O-rings reduce cable wear
- Dual-action tension release
- Built-in fall indicator for easy inspection
- Free wheel mode for jobsite use
- Designed for stability when tensioning
- Ergonomic carry handle
- Repairable by authorized center
SafeWaze 023-8091 Specifications
| Materials | 1/4 inch galvanized steel cable; steel and aluminum components; nylon and glass fiber housing |
| Length | 65 ft (19.8 m) |
| Weight | 24.2 lbs (11.0 kg) |
| System Capacity | Maximum 2 users per system |
| Minimum Breaking Strength | 5,000 lbs (2268 kg) |
| Peak Dynamic Pullout Load | 2,500 lbs (1134 kg) |
| ANSI Weight Capacity | 130–310 lbs (59–141 kg) |
| OSHA Standards | 1926.502, 1910.140, 1910.66 |
