Description
HCFS215-48 bearing is a 3″ bore four-bolt normal-duty flange bearing that utilizes an eccentric locking device to secure to a 3″ shaft. HCFS215-48 flange bearings are designed for circumstances where the bearing is mounted to a surface perpendicular to the shaft axis and poses great stability and rigidity due to the four mounting positions. Our superior HCFS215-48 bearing with a 3″ bore is equipped with a premium C3 precision insert bearing housed within a high-strength solid-base cast-iron housing. Additionally, our HCFS215-48 bearing has added features that improve the overall life and performance of the unit, such as; a steel retainer, wide inner-ring, anti-rotation device, and relubricating capabilities. HCFS215-48 bearings are commonly used in applications such as; construction equipment, agricultural equipment, forestry, aggregate, conveyor systems, and many more. Our HCFS215-48 bearing is dimensionally made to industry standards, meaning it interchanges with just about any brand out there. Contact our customer support team for further information or to get a quote on our HCFS215-48 bearings, and we will be happy to assist you!
HCFS215-48 Bearing Dimensions
- Part #: HCFS 215-48
- Shaft Diameter (d): 2-15/16″
- Dimension (A): 7.88″
- Dimension (E): 6.000″
- Dimension (I): 1.61″
- Dimension (G): 0.94″
- Dimension (L): 2.44″
- Dimension (S): 0.79″
- Dimension (Z): 3.78″
- Dimension (Bi): 3.6260″
- Dimension (N): 1.4685″
- Dimension (M): 1.4685″
- Bolt Used: 7/8
- Dynamic Load Rating (LBS): 14,974
- Static Load Rating (LBS): 10,757
- Bearing Insert: HC 215-48
- Housing Number: FS 215
- Weight (LBS): 17.4
