D12Btb26 Taper-Lock Sprocket — Compatible With 35Mm Bushings

Description

This D12BTB26 sprocket is a metric taper bushed style roller chain sprocket manufactured under ISO and British Standard 228. and is made to accept a 2517 taper bushing. Our D12BTB26 sprockets are made with reliability and performance in mind, so we use high-quality carbon steel (CS) and have the sprocket precision cut to ensure maximum performance and wear life. We also offer upgrades on our D12BTB26 sprockets such as black-oxide coatings and heat-treated hardened teeth, though we often have these specific sprockets with those features already added right off the shelf. Besides the 26 tooth sprocket, we also stock a high-quality 12B-2 roller chain, 2517 bushings, and a wide array of roller chain accessories. For more information or to get a quote on taper bushed D12BTB26 sprockets, please contact us and one of our sales team members will be happy to assist you.

D12BTB26 Sprocket Dimensions

• Sprocket Size: D12BTB26
• Tooth Count: 26
• Pitch Diameter: 158.04mm
• Bushing Size: 2517
• Maximum Bushing Bore: 63.5mm
• Dimension (L): 44.5mm
• Dimension (H): 130.0mm
• Sprocket Weight: 3.24 kg
• Bushing Weight: 1.30 kg
