Description
Our high-quality clamp collar for a 54mm splined shaft with 8 splines is precisely crafted from C45 steel, ensuring exceptional strength and superior holding power. It includes four pre-drilled holes, making it an ideal match for a splined hub with a flange. A splined clamp collar is a mechanical device designed to secure or position components on a splined shaft. Unlike standard clamp collars, it features internal splines that align with the shaft’s splines, providing a secure and precise fit. This design allows the collar to effectively transmit torque and resist rotational forces without slipping. For more details or to request a quote on our premium clamp collar for a 54mm splined shaft with 8 splines, please reach out to our customer service team, who will be happy to assist you!
54mm Splined Clamp Collar Dimensions
- Part Number: 64861400
- Material: C45 Steel
- Profile Description: KN 46 x 54
- Dimension (A): 100mm
- Dimension (B): 80mm
- Dimension (B1): 11.0mm
- Dimension (C): 65mm
- Dimension (d): 46mm
- Dimension (L): 24mm
- Dimension (K): 3mm
- Dimension (T): 11.0mm
- Dimension (S): M8
- Weight: 0.96KG
